Sigma 4BU – 27.5" Manual Tile Cutter for Ceramic & Porcelain
The Sigma 4BU is perfect for tight workspaces and standard-format tile. Offering up to 27.5 inches straight and 19.7 inches diagonal, it’s compact yet capable.
Max cutting length: 70 cm (27.5") straight, 500 mm (19.7") diagonal
Max tile thickness: 17 mm (0.67")
Sigma Series 4 UP Tile Cutter – Pull-Style Precision for Professional Tile Installers
The Sigma Series 4 UP Tile Cutter is a top-tier manual cutter engineered for professional tile installers who prefer pull-style operation and demand unmatched accuracy. Designed in Italy for ceramic, porcelain, and textured tiles, the UP cutter delivers exceptional scoring visibility and smooth, repeatable results on tiles up to 11/16" (17mm) thick.
With a visible 12mm scoring wheel, CNC-machined holder, and pull-style ergonomic handle, this cutter maximizes user control and scoring accuracy. Its durable construction includes a wide splitting foot with anti-mark protection, a wear-free carriage system using double-row ball bearings, and automatic tile leveling via a built-in steel compensator.
Features:
-
Pull-Style Incision Handle – Ergonomic grip for optimal control and reduced fatigue
-
12mm Scoring Wheel (Visible to Operator) – CNC-milled holder with enhanced precision
-
Optional TIN-Coated Scoring Wheel – Longer-lasting performance in high-use environments
-
Double-Row Ball Bearing Carriage – Wear-free glide system for consistent accuracy
-
Anti-Friction Shell – Ultra-smooth scoring motion
-
Splitting Foot with Anti-Mark Pads – Protects finished tile surfaces during snapping
-
Automatic Leveling Compensator – Ensures uniform pressure across varying tile thickness
-
Pivoting Guide Bar – Cuts angles up to 45° in either direction
Sigma UP Tile Cutter Specifications:
| Model | Sigma 4BU | Sigma 4CU | Sigma 4DU |
|---|---|---|---|
| Length of Cut | 27.5 in | 33 in | 40.5 in |
| Diagonally Cuts | 19.5 in | 23.4 in | 28.6 in |
| Weight | 23 lbs. | 27 lbs. | 32 lbs. |
